ĐỘNG CƠ CHUYỂN ĐỘNG P831SPZS0100ED806U STÖBER Antriebstechnik GmbH VIỆT NAM
LIÊN HỆ : 0916.597.556
MR TÚ , CUNG CẤP HÀNG CHÍNH HÃNG
P831SPZS0100ED806U
MV0000156820
replacement for serial no.: 10256761 but newest generation
Please note the enclosed dimension sheet.
Planetary geared motor
P831SPZS0100ED806U
Weight 73 kg
Stall current 42.2 A
Nominal current 21.5 A
Ratio 10.00
Exact math. ratio 10/1
Motor torque 22.0 Nm
Stall torque 456 Nm
Output torque 213 Nm
Max. input speed cycle 4,500 rpm
Motor speed 4,200 rpm
Output speed 420 rpm
Motor power 9.68 kW
Backlash 3.0 arcmin
Service factor 2.8
Shaft design Solid shaft with key
Output bearings Radial reinforced bearings
Shaft dimension Ø55x82 *
Housing design □190 pilot 160 BC 215 *
Mounting position Any
Lubrication Mobil SHC 629
CLP HC ISO VG 150
Type designation ED/EK motor ED806USACQRO100
Cooling type Convection cooling IC
Drive controller manufacturer STOBER
Encoder plug connec. sz./type STOBER drive controller con.23
DC link voltage 540V DC link voltage
Drive controller type / conn. MDS/SDS 5 sin/cos
Connection plan 442074
Encoder type EnDat multi-turn analog
Encoder model Ind. 2.1 EQI 1331
Nominal speed nN 4200rpm 540V (KEM=100) ED
Connector type Angle rotatable
Mating connector W/o mating connector
Power connection Plug connector 8-pole con.40
Pos. of the plug connectors 270°
Cable entry Left *
Thermal winding protection PTC in power connection
Thermal class (VDE 0530) 155 F
Protection class (EN 60529) IP56 (EN 60529)
Option design UR / CSA Recognized Components
Operating mode servo motors S1 Operating
Paint K / 1-layer paint
Color RAL 9005 deep black
Paint options Output unpainted
Special note: To ensure trouble-free function of the motors and drive controllers we recommend the use of ourmatched cables. In case of use of unsuitable connection cables, we reserve the right to reject claims
under the warranty.
Attention: The plug connectors on the motor are designed in SpeedTec® as standard.Cables with screw connectors can also be used for connection. In this case, o-ring no. 5050023(con.23) / 5050040 (con.40) must be retrofitted to the motor plug connectors to prevent unintentional
loosening of the connection (vibration).
